Maps of the Metro Rail Lines

More complete information on each of Metro Rail's planned lines is provided in this section.

Buffalo's Metro Rail was designed for 46 miles of route, reaching the Buffalo-Niagara International Airport, the University at Buffalo North Campus, Niagara Falls, and the Southtowns. Currently, Buffalo's Metro Rail extends from the former D,L&W Terminal (the Metro Rail barns) to the South Campus of the University at Buffalo, a distance of 6.4 miles. The existing Metro Rail's southernmost one mile is at grade on Main Street, and the balance of the system is underground in mixed cut/cover and deep bored tunnel.

Click here for an interactive Google map of the Metro Rail lines.

Attached below is a copy of our display map that you may see at events! It shows every road and street in detail along with where the corridors and stations are located. (25MB, PDF)

[Schematic map of new Metro Rail Lines - 115K]
